Liposyn Z

Description

The Liposyn Z is used for high throughput production of nanoparticles (LNP, microemulsions, etc.) using a hedonic flow mixer. The device contains 3 pumps that enable in-line dilution of mRNA, assembly of lipids and mRNA into LNP in a convective flow mixing chip and timely dilution to prevent particle size changes.

Technical specifications

Hedge flow mixed metal chip, chip is 316L stainless steel materialAPI on-line dilution and LNP dilution function.Preparation flow rate up to 450 ml/minMaximum working pressure, 10MpaHigh-pressure infusion pumps, 3 sets, maximum 15Mpa, flow rate accuracy, ≤ ±2%High-precision flow meter, 3 sets, RS-232 communication, 24VAutomatic electronic switching valve, online real-time switching liquid pipeline3 liquid connection clamp inlets, different connections available on request2 liquid connection clamp outlets, different connections available on request.Temperature range of the feed liquid, 4-60 °CLiquid contact materials, 316L stainless steel, PEEK, PTFE, aluminum oxide (Al2O3), ruby, all materials are cGMP compliantOperating software, 21 CFR Part 11 GAMP5 compliant
