Liposyn X

Description

Powered by a precision syringe pump that enables controlled and precise assembly of lipid nanoparticles (LNPs), the Liposyn X instrument is easy to use and requires minimal setup and training to automate the synthesis of gene drugs.

Technical specifications

All-in-one machine, no need for an external computer, full touch screen click settings2 independent liquid delivery channelsSample volume: 0.4mL~15mLControllable total flow rate range, 0.04 mL/min - 36 mL/min (ethanol and water 1:3)Accuracy of flow rate within ±2With flow rate calibration function, you can get more accurate flow rate by calibration.Automatically detects the syringe piston position and automatically determines the start position.Equipped with 1 ml, 3 ml, 5 ml, 10 ml syringe adaptersSuitable for syringe types from 1 mL to 10 mL, with built-in parameters for commonly used syringe types.Automatic switching between pre- and post-disposable waste liquids, volume of pre- and post-disposable waste liquids can be set in the software.Equipped with standard LNP synthesizer chip to prepare LNP particles from 40 - 200 nm.Chips are pressure resistant to 5 MPa and made of COC material.Customized chips are available
